Momentary Surface Mount LED Tact Switch
Momentary Surface Mount LED Tact Switch This is surface mount illuminated tact switch with high bright LED color options,it’s a momentary action illuminated tactile switch,there is a sharp tactile and audible click feedback,it offers gold plated dome contact with stable reliability.Long travel...
Description
Momentary Surface Mount LED Tact Switch
This is surface mount illuminated tact switch with high bright LED color options,it’s a momentary action illuminated tactile switch,there is a sharp tactile and audible click feedback,it offers gold plated dome contact with stable reliability.Long travel makes the obvious feedback when you press it down.
Item | Standard |
Rating | 50mA 12VDC |
Insulation Resistance | 1GΩ Min (at 250 VDC) |
Dielectric Strength | AC 250V (50/60 Hz for 1 minute) |
Contact Resistance | 100mΩ Max. (Initial) |
Electrically Life | 100,000 Cycles Min |
Ambient Temperature | -45°C~ +125°C |
Operating Force | 400 ± 100gf |
Total Travel | 0.8 ± 0.1mm |
Contact arrangement | Normally Open |
Feature
• Miniature structure with long traveling.
• A variety of LED colors options.
• Customized cap and symbols are available.
• Combination of switch linked with LED avoid the LED failure during high-temperature processing.
Typical Applications
• Application requiring illumination
• Server, storage
• Network infrastructure
• Telecommunications
• Medical
Common Packaging Methods
1. Skin packing for switch with cap style in bulk packing
2. PE bag for no led type,anti-static bag for led tact switch without cap type are in loose packing
Our Customers
We have close cooperation with professional audio and video industries customers,through our effort,our customers spread all over the world.
Exhibition Display
FVWIN manufactured the illuminated tact switches for 10 years,we’ve entered into Electronica China 2020 and 2021 in Shanghai,during the hall,we displayed the illuminated tact switches and led push button switch for customers at home and abroad.we received many customers and obtains good reputation.
