LED 90 Degree Tact Switch
This is TS20 series is tactile switch with right angle and side actuated through hole model,it has a N.O. momentary action,Bi-color LED illuminated available,This switch is perfect for computer products, communication equipment, home appliance products. The illuminated right angle tact switch...
Description
This is TS20 series is tactile switch with right angle and side actuated through hole model,it has a N.O. momentary action,Bi-color LED illuminated available,This switch is perfect for computer products, communication equipment, home appliance products.
The illuminated right angle tact switch series models have side actuator mechanism and are available in the following compact sizes, TS20 series size is 7.6mm x 8.7mm,The ts20 series illuminated tactile switch contain a single LED color display with a bi-color option independent of the switching function. A dome contact structure provides excellent tactile feedback to the user, with a switch life up to 500,000 cycles.
· SPECIFICATIONS.
· CONTACT RATING: 12VDC 50mA.
· MECHANICAL LIFE: 50,000 Cycles.
· CONTACT RESISTANCE: 100mΩ at 5VDC Initial Max.
· INSULATION RESISTANCE: 100MΩ Min. at 100V.
· DIELECTRIC STRENGTH: 250VAC.
· FORCE: 160 ± 50gf; 250 ± 50gf.
· TRAVEL: 0.25mm ± 0.1mm.
Features/Benefits
• right angle thru-hole models
• Multiple caps and legends
• Several LED colors and bi-color options
• RoHS compliant /compatible
Typical Applications
• Consumer electronics
• Server/storage
• Medical devices
• Test/Measurement/Instrumentation
• Audio/Video
• Computers/Peripherals
• Security
