8 Pin 3-Position Slide Switch Vertical

This is 8 Pin 3-Position Slide Switch Vertical, it has eight terminals and three position to control the circuit.

Featuring ultra-miniature, micro, miniature, standard, industrial and power versions, we have slide switches compatible for PCB, surface mount and panel mount applications. Available in SPST, SPDT, SP3T, DPST, DPDT, 3PDT, 4PDT and 4P3T functions,

Equipped with industrial-grade copper contacts and precision conductive structures, the product achieves a contact resistance as low as ≤50mΩ. This effectively minimizes signal attenuation and energy consumption, ensuring stable transmission of both weak signals and power currents. With an insulation resistance of ≥100MΩ and the ability to withstand a dielectric strength of AC500V 50Hz/1Min, it completely eliminates risks of electric leakage and breakdown. Combined with a mechanical lifespan of ≥10,000 cycles, it maintains consistent performance even under high-frequency switching scenarios, meeting the requirements for long-term reliable operation. It also complies with the RoHS environmental standard, with no harmful substance residues, making it fully compatible with global electronic device compliance regulations.

1, right angle and through hole is available

2,Many function options

3,Featuring ultra-miniature, micro, miniature, standard, industrial and power versions.

Featuring a vertical through-hole structure with a compact main body (typical dimensions: 16x7x17mm), the vertical mounting method maximizes horizontal space savings on PCBs, making it ideal for miniaturized, high-density electronic devices. The 5mm standard handle height, paired with a smooth sliding mechanism, ensures an operating force of 200±100gf. The crisp tactile feedback and clear gear positioning during switching effectively prevent misoperation, balancing convenience and precision. The 8-pin dual-row regular layout with standard pin pitch enables accurate soldering alignment, suitable for both novice operators and mass production, significantly improving assembly efficiency.

1. 10-years manufacture experience in switch industry

2. 100% test before packing the products to ensure the high quality

3. Competitive price and prompt shipping

4. Accept OEM & ODM, please send us samples or specification for evaluate.

FVWIN ELECTRONICS offers illuminated tact switch and illuminated push button switches solutions for the electronics switches industries.Our clients include broadcast film and video industries, medical equipment, security equipment, industry control industries.FVWIN will exceed your expectations with state of the superior service standards.

Q1: What does "8 Pin 3-Position Vertical" mean for this slide switch?

A1: It refers to a vertical-mount slide switch with 8 pins (terminals) and 3 operating positions. The 8 pins form a 2P3T (2 Pole 3 Throw) configuration, allowing control of two independent circuits simultaneously, with three selectable modes (e.g., Off-Mode 1-Mode 2 or Signal Path A-B-C) for flexible circuit switching.

Q2: What is the core application scenario of this switch?

A2: It is widely used in devices requiring multi-mode or multi-circuit switching, such as audio input selectors, smart light mode controllers, power gear regulators, industrial control modules, electronic toys, and DIY maker projects. Its compact vertical design makes it ideal for small, high-density PCB layouts.

Q3: What are the key electrical performance parameters?

A3: The switch features industry-grade electrical performance: contact resistance ≤50mΩ (low signal attenuation), insulation resistance ≥100MΩ (anti-leakage), and voltage resistance of AC500V 50HZ/1Min (no breakdown risk). It operates stably for both weak signals and power currents.

Q4: What is the mechanical lifespan and operating feel?

A4: It has a mechanical lifespan of ≥10,000 cycles, maintaining consistent performance in high-frequency switching scenarios. The operating force is controlled at 200±100gf, with a crisp, clear tactile feedback and distinct detents between positions to avoid misoperation.

Q5: What is the installation method and size specification?

A5: It adopts a vertical through-hole (THD) mounting design, with a typical compact size of 16x7x17mm (LxWxH) and a standard 5mm lever height. The 8 pins are arranged in two rows with standard spacing, ensuring precise positioning during soldering and easy assembly for both small-batch and mass production.
