Description

AC Power Supply Socket with Fuse integrates the IEC C14 inlet with a 5×20 mm fuse holder into a single module to realize both connection and overcurrent protection at the power inlet.

Products Description

AC Power Supply Socket with Fuse

The AC Power Supply Socket with Fuse combines an IEC 60320 C14 male inlet and a 5×20 mm fuse holder in one housing. This design allows equipment manufacturers to integrate an AC power inlet and fuse protection into a single panel opening.

When selecting this component, buyers should consider more than the presence of a fuse holder. It is important to check the fuse pole configuration against the electrical safety requirements of the target market, choose a fuse replacement method that suits the equipment, and confirm that the fuse holder meets the required fault current rating.

Products Overviews

Fuse Specification 5 × 20 mm(without fuse holder)
Fuse Holder Poles 1-pole or 2-pole optional
Rating Current / Voltage(IEC) 10 A / 250 VAC,50 Hz
Rating Current / Voltage(UL/CSA) 10 A / 250 VAC,60 Hz
Terminal Model 4.8 × 0.8 mm quick connection terminal
Installation Method Snap-in / flange scew fastening
Housing Material Thermoplastic, Black, UL94V-0
Safety Certification UL/cUL,VDE,ENEC

Main Features

  1. Shocksafe PC2 fuse holder safety rating: no live parts exposed when replacing the fuse.
  2. Fuse replacement methods: tool-operated opening vs. tool-free opening, tailored for terminal application scenarios.
  3. Power acceptance value 1.6 W per pole (2 poles): determines whether the fuse can avoid unwanted tripping under full load.
  4. Fuse replacement methods: tool-operated opening vs. tool-free opening, tailored for terminal application scenarios
product-1-1

FVWIN manufactures illuminated tact switches, pushbutton switches, toggle switches, sockets and connectors.

With seasoned professionals and modern production technology, we produce quality components meeting industrial standards and provide custom-fit switch and connector solutions.

We prioritize efficient communication and on-time support. Our team is ready to answer your questions and assist with your technical and order enquiries.

We aim to build stable, long-term cooperation with customers. We hope to support your projects with dependable products and services.

Exhibitions

We have participated in Electronica China in Shanghai from 2020 to 2026. We displayed our illuminated tact switches and LED push button switches to visitors and earned positive feedback from customers.

2-




view more

3




view more

-1




view more

5




view more

FAQ

Q: Should I choose a 1-pole or 2-pole fuse holder for my equipment?

A: 1‑pole cuts only live (L), suited for most general and Class I earthed devices; the default for cost‑sensitive projects. 2‑pole disconnects both L and N, required for medical equipment (IEC/UL 60601‑1), Class II double‑insulated units and grids where neutral may float. Choose by equipment class and regional safety rules, not simply for extra protection.

Q: Is the fuse holder tool-operated or tool-free? Can the tool-free version be used in medical devices?

A: Both styles are offered. Tool‑free access suits general equipment where end users may replace fuses. Tool‑operated access (screwdriver required) is for medical devices, industrial cabinets and applications restricting unauthorised tampering; medically approved holders normally require tools. Select according to your manual's definition of user‑serviceable parts to match the intended service level.

Q: Does the product come with a fuse? If not, how should the fuse be selected during procurement?

A: Fuses are not supplied; holders ship empty. Buyers select 5×20 mm fuses separately, based on operating current, inrush and local standards such as IEC 60127 or UL 248. Check that the holder power rating (1.6 W per pole at 23°C for two‑pole types) matches fuse dissipation. Derating curves apply for high‑temperature use.
