2 Position Momentary Toggle Switch
The TG Series sub-miniature toggle switch is offered with both Single Pole, Double Throw (SPDT) and Double Pole, Double Throw (DPDT) circuits. These sub-miniature toggle switches perform both momentary or maintained (latching) functions and come with either non-threaded or threaded bushings...
Description
The TG Series sub-miniature toggle switch is offered with both Single Pole, Double Throw (SPDT) and Double Pole, Double Throw (DPDT) circuits. These sub-miniature toggle switches perform both momentary or maintained (latching) functions and come with either non-threaded or threaded bushings options.
Solder and PCB mounting two different termination options are also available, including a toggle switch mounting bracket for vertical PC board mounting. Applications for these sub-miniature toggle switches include:Telecommunications, Instrumentation, Networking, Medical equipment devices and industrial equipment.
DETAIL SPECIFICATIONS
|
ELECTRICAL RATING: Dependent on Contact Material |
MECHANICAL LIFE: 30,000 Make-and-Break Cycles
|
CONTACT RESISTANCE: 10mΩ Max. Initial for Both Silver and Gold Plated Contacts |
|
ELECTRICAL LIFE: 6,000 at Full Power
|
INSULATION RESISTANCE: 1,000MΩ Min. |
DIELECTRIC STRENGTH: 1,000V RMS at Sea Level
|
|
OPERATING TEMPERATURE: -30°C to 85°C |
MATERIALS / CONTACTS: Silver or Gold Plated Copper Alloy
|
Mounting: solder tag / PCB |
Dimension
Product Views
