6*6 Waterproof Tactile Switch

The TS60 series SMD waterproof tact switch is 6.0x6.0mm tactile switch button,it features the IP67 waterproof level,this tact switch has through hole and surface mount terminal options,the height has choice of 4.3mm/5.0mm/6.0mm/6.5mm/8.5mm/9.0mm/9.5mm/13.0mm/15.0mm.

The waterproof function will play an important role in the outside applications,such as outside instrument and apparatus, industry control equipment and so on,the surface mount is more convenient for soldering when you have the mass production.

The material are adopted the temperature-resistance,and it includes the waterproof gasket and membrane to promise the waterproof function.

Technical Specification

1. Rated:50mA 12VDC

2. Contact Resistance:100mΩ

3. Insulation Resistance:100MΩ

4. Actuation Force:180/250±50gf

5. Travel:0.25±0.1mm

6. Lifespan:100,000 cycles

7. Waterproof Level:IP67

Material

(1) Button :PPA temperature-resistance 280(black)

(2) Cover:PPA temperature-resistance 280(black)

(3) Waterproof gasket :silicone temperature-resistance 280(black)

(4) Waterproof Membrane :PI temperature-resistance 280(black)

(5) Dome :stainless steel(silver coated)

(6) Base: PPA temperature-resistance 280(black)

(7) Terminal : brass (silver plated)

Product Views

Dimension

Shipment

1.We will ship the goods after confirming payment;

2.Ship by UPS/DHL/TNT/Fedex. Pls contact us directly and we will use your preferred ways.

3.Goods will be sent out soon, within 1-3 days once we have stocks;

Packing

1. PE bag for DIP type

2. Plastic conta for the etched cap type

3. Tape packing for SMD type if there is bulk order

After-sales

Excellent after-sales service will be provided by us to satisfy our customers,we keep consistent prompt reply and cooperation for customers’ questions.

Cooperation Clients

80% Percent of our products are widely exporting to Europe, North&South America, Asia.We satisfy all our customers with advanced products, competitive prices, fast delivery and one-stop service.
