Illuminated SPST Push Button Switch
This is the circle diameter 9.6mm momentary illuminated push button switch,the top round button has size of diameter 5.6mm,the cut out size is 8mm.The case and housing is made from high-quality Nylon 6/6 and terminal is made from copper alloy with gold plated material. The total length of a push...
Description
This is the circle diameter 9.6mm momentary illuminated push button switch,the top round button has size of diameter 5.6mm,the cut out size is 8mm.The case and housing is made from high-quality Nylon 6/6 and terminal is made from copper alloy with gold plated material. The total length of a push button switch is 18mm. It has illuminated water clear actuator.
This miniature push button switch with momentary switch operation and 1-pole on-off switch for controlling a machine or a process.
The PB8 Series illuminated pushbutton switch is available with bi-color LED choices of red, green, yellow, blue and white. Panel mount and small in size the PB8 series is SPST and momentary, with silver or gold contact option. This illuminated push button switches features 100,000 electrical life cycles and PC pin terminal options. The illuminated panel mount button switch is made with polycarbonate actuators, nylon housing, and alloy materials for the contacts and terminals.
Basic Parameter
Electrical Specifications | |
Rating | 0.2A 36VDC |
Contact Resistance | 50MΩ Min(Initial) |
Insulation Resistance | 100mΩ Min(at 250VDC) |
Dielectric Strength | AC 500V(50-60HZ for1 m) |
Mechanical Life | Over 30,000 cycles |
Electrical Life | Over 10,000 cycles |
Actuation Force | 200±100gf |
Travel | 1.8mm±0.3mm |
Function | OFF-(ON) |
Manual Welding | 350℃ for 3 Seconds |
LED Color | Red,green,white,yellow,blue |
Material | |
Base | PA66,UL rated:94 V-2 Min |
Cap | PC |
Terminal | Copper,Golden plated |
Panel Cut Out Size | 8 (Dia.)mm |
Terminal Type | Pc Pin
|
Switch Operation | Momentary |
Mounting Type | PCB |
Dimension
Soldering Procedure Attentions
1. The illuminated push switch is strictly prohibited wave welding and reflow soldering,please choose the manual welding procedure,and control the welding temperature of 350℃±5℃ for 3±5 seconds
2. After the product is soldered on the PCB board,it’s prohibited to use any solvent to clean the PCB board and please avoid the influence of the inner product.
Typical applications for this miniature illuminated push button switch would be:
• Test Equipment
• Telecommunications
• Networking
• Handheld Appliances
Packaging Details
Stand Exported Packing for computer power switch:
inner bubble box--- inner box---carton (or by your request.)
Shippment
FedEx/ UPS/ TNT/ DHL account number for shipping,if not,we need to charge the freight to your company.
