DC Power Jack Socket Connector

The DC Power Jack Socket Connector DC-005 is a type of electrical connector commonly used for providing a power input or output in electronic devices. Here's an introduction to its key features and characteristics, specifically for the DC-005 model with a 5.5 x 2.1mm round-pin configuration:

1. DC Power Jack Design:

The DC-005 is a power jack socket designed to facilitate the connection of DC power sources to electronic devices. It typically features a cylindrical connector with a specific pin configuration.

2. Connector Size:

The DC-005 model has a 5.5 x 2.1mm connector size. This specification refers to the inner and outer diameters of the cylindrical connector tip, which is a standard size for DC power connectors.

3. Round the Needle:

The "round the needle" description likely refers to the circular shape of the connector pin or terminal. The round needle shape helps ensure a secure and stable connection.

4. Center Pin Positive Polarity:

In the 5.5 x 2.1mm DC power connector standard, the center pin is typically positive (+), and the outer sleeve or ring is negative (-). This standard polarity ensures consistency in wiring practices.

5. Panel Mountable:

The DC-005 power jack is often designed for panel mounting, allowing it to be securely attached to control panels, device enclosures, or other surfaces.

6. Easy Installation:

The design of the DC-005 makes it relatively easy to install on a variety of surfaces. It may include mounting holes for secure attachment to the panel.

7. DC Power Supply:

Designed specifically for DC (Direct Current) power, the DC-005 connector is commonly used in electronic devices such as power adapters, routers, audio equipment, and other applications requiring a reliable power input or output.

8. Commonly Used Standard:

The 5.5 x 2.1mm connector size is a widely used standard in the electronics industry, ensuring compatibility with a broad range of devices and power supplies.

9. Versatile Applications:

The DC-005 model is suitable for a variety of applications where a stable and reliable DC power connection is required. Common applications include power supplies, chargers, and electronic devices with external power sources.

10. Metal Construction: - The connector pins are often made of metal to ensure conductivity and durability. Metal construction also provides resistance to wear and tear.

11. Compatibility: - The DC-005 connector is compatible with various power adapters and devices designed to use the 5.5 x 2.1mm DC power jack.

When considering the use of a DC Power Jack Socket Connector DC-005 in your electronic design, it's important to refer to the manufacturer's specifications and guidelines for proper installation and compatibility with your specific application.
