16mm Round Head Momentary Nickel Plated Brass Push Button Switch (V16-B)
The pb02 series momentary push button switch with cut-out size 16mm and provides red, green, gray, yellow. blue top button color options, we also welcome to customized the symbols on the button surface, it’s widespread applied to household appliances, fruit juice beverage machine, electronic lock system, automobile, vending machines.
Description
We always insist on building a platform for the growth of our employees and doing our part for the development of the Illuminated Push Button Switch, Illuminated Push Button Switch For DMX Console, Momentary Tactile Switch Button industry. Our products are trusted, our services are affirmed, we cherish every fate, and we respect every penny of our customers. We are committed to building a world-class company and creating a better working environment for the company. We clear know that "technical innovation is the driving force of an enterprise" is not only a courage, but also a warning. After years of development in the industry, we have very rich experience, and the perfect management system makes our product quality more secure.
Product Profiles
The pb02 series momentary push button switch with cut-out size 16mm and provides red, green, gray, yellow. blue top button color options, we also welcome to customized the symbols on the button surface, it’s widespread applied to household appliances, fruit juice beverage machine, electronic lock system, automobile, vending machines.
PB02 Push Button Switches Series
Model | PB02 |
Rating | 6A 125VAC, 3A 250VAC |
Contact resistance | 50mΩ(MAX) |
Insulation resistance | DC500V 100MΩ(Min) |
Withstanding voltage | 1000VA C for 1 minute |
Life | 10, 000 cycles |
Total travel | 2.0±0.4mm |
Operation force | 150±100gf |
Mechanical life | 50, 000 cycles Min |
Temperature | 0℃~85℃ |
Function | OFF-(ON) |
Materials
Base on the cover: chrome plated brass
Under the base cover: PBT,
Handle: ABS.
Terminal: red copper plating silver
Nut: zinc alloy
Characteristics
SPST, push ON
Optional button color;R=red, B=black, G=green
Panel cutout :diameter.16 for PB-02
Metal or plastic Bezel
Hardware accessories supplied
Exhibition Experience
We’ve take participated in Electronica China in 2020 and 2021at Shanghai, we showed our illuminated tact switch and led push button switch for customers and got good reputation from them.
FAQ
Q: What about the delivery time?
A: Stable delivery. 7-15 working days.
Q: Do you provide customized services?
A: Yes, we support OEM/ODM service.
Q: Is there quality control on all production lines?
A: Yes, all production lines have adequate quality control.
We are more open, more inclusive, providing more competitive 16mm Round Head Momentary Nickel Plated Brass Push Button Switch (V16-B) for customers, with more preferential prices, more professional services, consulting, after-sales service a whole set of system to do more perfect. Our company will continue to bring you more choices, more trust and benefits. Our code of conduct is that everything is result-oriented, and we prove everything with results.
